Detalles del producto
Lugar de origen: China Shenzhen
Nombre de la marca: HSCXLED
Certificación: KC CE ROHS FCC CCC ISO9001
Número de modelo: P6.25
Condiciones de pago y envío
Cantidad de orden mínima: 1 conjunto
Detalles de empaquetado: Caja de madera/caja de panal/estuche de pelea
Tiempo de entrega: 10-15 días de trabajo
Condiciones de pago: L/C, T/T, D/A, D/P, Western Union, Moneygram
Capacidad de la fuente: 1000 conjunto
Nombre del producto: |
Pantalla de película transparente LED |
Solicitud: |
interior, al aire libre |
Tipo: |
Pantalla de película Led |
luz LED: |
SMD1515 |
Modelo:: |
P6.25 |
Permeabilidad: |
90%~ 95% |
Brillo: |
2000 y 2000 |
Voltaje de entrada: |
AC110-240V50/ 60 Hz |
Potencia promedio: |
200 W/m2 |
Esperanza de vida: |
100000 horas |
Nombre del producto: |
Pantalla de película transparente LED |
Solicitud: |
interior, al aire libre |
Tipo: |
Pantalla de película Led |
luz LED: |
SMD1515 |
Modelo:: |
P6.25 |
Permeabilidad: |
90%~ 95% |
Brillo: |
2000 y 2000 |
Voltaje de entrada: |
AC110-240V50/ 60 Hz |
Potencia promedio: |
200 W/m2 |
Esperanza de vida: |
100000 horas |
This New Technology Indoor Transparent LED Film Screen offers high transparency up to 95%, making it ideal for glass curtain walls and retail environments. With a thin profile of just 2.5mm thickness, it supports versatile display functions including video, pictures, text, animation, and cartoons. The product ensures vibrant visuals with brightness levels of 2000/4000 CD/㎡ and a wide viewing angle of 160°. Certified with CCC, KC, CE ROHS FCC, it guarantees compliance with quality and safety standards, enhancing market access for buyers.
The core usage characteristics of LED film screen are light, thin, flexible, high transparency and invisibility, which can adapt to special carriers such as glass curtain walls, and balance display function with the original appearance of the building.
![]()
| Model | P3.75 | P5 | P6 | P8 | P10 | P15 | P20 | P30 |
|---|---|---|---|---|---|---|---|---|
| Pixel pitch | 3.75*3.75mm | 5*5mm | 6.25*6mm | 8.125*8mm | 10*10mm | 15*15mm | 20*20mm | 30*30mm |
| Pixel density | 71,111 Pixels/m² | 40000 Pixels/m² | 26,560 Pixels/m² | 15,375 Pixels/m² | 10,000 Pixels/m² | 4444 Pixels/m² | 2500 Pixels/m² | 1,111 Pixels/m² |
| Module Resolution | 144×64Pixel | 144×48Pixel | 160×40Pixel | 123×30Pixel | 100×24Pixel | 64×16Pixel | 50×12Pixel | 32×8Pixel |
| Module size (W*H*T) |
540mm *240mm |
720mm *240mm |
1000mm *240mm |
1000mm *240mm |
1000mm *240mm |
960mm *240mm |
1000mm *240mm |
960mm* 240mm |
| Weight/pcs | 0.18Kg | 0.2Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg |
| Installation method | Glass direct/clamp tempered glass inner/inner arc installation | |||||||
| Brightness | 1500-2000/3500-4000cd/m² | |||||||
| H/v viewing angle | 140°/140° | |||||||
| Evenness | ≥98% | |||||||
| Highest contrast ratio | 4,000:1 | |||||||
| Protection level | IP43 | |||||||
| Colour | 16bit | |||||||
| Refresh rate | ≥3,840Hz | |||||||
| Change frame frequency | 60Frame /Second Suppot High Resolution3D:120Frame | |||||||
| Screen color temperature | 2,000K~9,500K /Adjustable | |||||||
| Interface | Windows | |||||||
| Working voltage | AC:110V~240V,50~60Hz | |||||||
| Peak power | ≤160W/m² | |||||||
| Average power | 50W/m²~60W/m² | |||||||
| Continuous working hours | ≥7×24h | |||||||
| Mean time between failures | ≥100,000h | |||||||
| Screen temperature rise | ≤3°(during use) | |||||||
| Operating ambient temperature |
-10~60℃ | |||||||
| Operating environment humidity |
10%~90%RH/No condensation | |||||||
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
